NFS on k3d inside GitHub Codespaces

I need to use NFS with Kubernetes in GitHub codespaces for reasons. k3d¹ already handled my throwaway clusters nicely, so the obvious move was to add an NFS-backed² ReadWriteMany volume via nfs-subdir-external-provisioner. I expected it to “just work.”

It did not. Pods sat in ContainerCreating until they timed out with mount.nfs: Operation not permitted, the same failure called out in k3d issue #1109. The root cause is boring but important: the stock k3s image ships from scratch³, so it contains none of the NFS client tools (nfs-utils, rpcbind⁴, or even the OpenRC⁵ metadata needed to start services). GitHub Codespaces run on cgroup v2⁶, and k3d tries to be helpful in that environment by swapping in its own entrypoint script, which meant every hand-rolled fix I wrote was silently discarded.

This post explains each speed bump and how it became this repo:

Trying someone else’s fix

The GitHub issue links to marcoaraujojunior’s Dockerfile through a commit mention.

On paper it solved everything: start from Alpine (a small Linux distro), install the NFS client tools, copy the official k3s binaries on top, and run a short entrypoint script that turns on the NFS service before handing control to k3s. There was no registry image at the time, so the flow looked like this:

docker build -t k3s-nfs:trial .
k3d image import k3s-nfs:trial -c test
k3d cluster create test \
  -i k3s-nfs:trial

The cluster booted, but kubectl describe pod still showed Not supported while mounting. Inside the node container, rpcinfo -p and rc-service nfs status both reported “service not running.” The tools were installed, but the init system (OpenRC) never ran its startup sequence because the container lacked the usual bookkeeping files. Copying someone else’s Dockerfile got me 80% of the way there, but the missing 20% was still the part that actually starts NFS.

Teaching OpenRC to behave

OpenRC (the init system Alpine uses) checks /run/openrc/softlevel⁷ to decide whether “boot already happened.” I found that clue after tailing /var/log/rc.log inside the container and noticing OpenRC yelling about “softlevel unset,” so the service would immediately exit. The k3s image never creates the file, so rc-service nfs start fails quietly and nothing mounts. The simplest fix is to create the directory and the file yourself before trying to start anything because that file is literally the “current runlevel” marker.

RUN mkdir -p /run/openrc \
    && touch /run/openrc/softlevel

That tiny change plus explicit rc-update add rpcbind/rc-update add nfs finally let rc-service nfs start succeed. I kept Alpine as the base image so I could install nfs-utils/rpcbind for the client bits, iptables/ip6tables so kube-proxy can still program filter/NAT rules, and openrc itself to coordinate the services. After that I copied the k3s binaries straight from the official image. The full Dockerfile is in the repo, but the important bits look like this:

FROM alpine:3.15
RUN apk add --no-cache iptables ip6tables nfs-utils rpcbind openrc
RUN rc-update add rpcbind && rc-update add nfs
RUN mkdir -p /run/openrc && touch /run/openrc/softlevel
COPY --from=rancher/k3s:v1.29.1-k3s1 /bin /bin
COPY k3d-entrypoint-nfs.sh /bin/
ENTRYPOINT ["/bin/k3d-entrypoint-nfs.sh"]
CMD ["agent"]

k3d-entrypoint-nfs.sh is deliberately boring: wait a few seconds (Codespaces are noisy during boot), make sure /run/openrc/softlevel exists, start NFS, then hand control to /bin/k3s. With that in place, rc-status finally reports that nfs and rpcbind are running before Kubernetes touches any volumes.

When k3d helpfully replaces your entrypoint

Here’s the part that kept me up: k3d detects cgroup v2 hosts (Codespaces, most modern Docker installs) and swaps in its own entrypoint to apply kernel fixes. That is a good default, but it also overwrites whatever entrypoint you added, so my NFS startup script never ran. You can brute-force your way through by setting export K3D_FIX_CGROUPV2=false before k3d cluster create, which tells k3d “please keep your hands off my entrypoint.” That was my first workaround.

That diagnosis took longer than I care to admit because the custom entrypoint logs land under /var/log/k3d/ inside the node rather than in docker logs, so every attempt looked like a silent success. I also learned the hard way that k3d v4 and older simply don’t support custom entrypoints for server nodes, so this trick only works on newer releases.

After I shared my workaround with the issue thread, iwilltry42 pointed out that k3d runs every script that matches /bin/k3d-entrypoint-*.sh. Dropping my script into that path means I can keep k3d’s default entrypoint and run my custom logic. Modern k3d releases include that hook, so disabling K3D_FIX_CGROUPV2 is only needed for older versions.

Putting it together

Once everything worked locally, I pushed the image to GitHub Container Registry (GHCR) so future clusters could skip the docker build/k3d image import dance. With the published image available, the full workflow inside a Codespace (or any Docker host) is only a few commands:

# Optional: inspect the published images
docker pull ghcr.io/jlian/k3d-nfs:v1.29.1-k3s1

# Create the cluster with the image
k3d cluster create nfs \
  -i ghcr.io/jlian/k3d-nfs:v1.29.1-k3s1

# Install the provisioner like normal
helm repo add nfs-subdir-external-provisioner \
  https://kubernetes-sigs.github.io/nfs-subdir-external-provisioner/
helm install nfs nfs-subdir-external-provisioner/nfs-subdir-external-provisioner \
  --set nfs.server=host.k3d.internal \
  --set nfs.path=/

docker pull just caches the image locally so cluster creation is faster. k3d cluster create spins up the control-plane node and worker containers using the NFS-capable image. The last two commands install the upstream Helm chart that creates and manages the NFS server inside the cluster.

If you’re running an older k3d release that predates the /bin/k3d-entrypoint-*.sh hook, set K3D_FIX_CGROUPV2=false before k3d cluster create so the custom entrypoint gets a chance to run.

Once the cluster is up, new pods stop complaining about Not supported, PersistentVolumeClaims bind as ReadWriteMany, and I can keep iterating without leaving the Codespace. The repo README lists the exact environment I tested (k3d v5.5.1 inside mcr.microsoft.com/devcontainers/universal:2-linux) along with the Docker and kernel versions in case you need to compare notes. Here’s that setup at a glance:

Loose ends

There are still things I want to revisit. The image currently copies k3s binaries straight into /bin, which matches what rancher/k3s does but makes me nervous about Alpine updates. I’d also like to script the Codespaces bootstrap so older clusters automatically decide whether they need K3D_FIX_CGROUPV2=false. Even with those rough edges, touching /run/openrc/softlevel plus the k3d-entrypoint-*.sh hook has held up ever since that night, and now I can spin up RWX storage anywhere k3d runs.
